Awning window system with easyZIP guidance

Perfectly fitting sun shading system

There is an easy way! With the new awning window systems with easyZIP guidance, you have planning freedom. The awning is perfectly integrated into exterior insulation and finish systems and, thanks to the cover panels embedded in plaster and guide rails, a harmonious feel is achieved. You can decide if the lateral guidance should be another visible design element or if you want to enjoy the convenience of the easyZIP guidance.

The benefits for you

• Unobtrusive integration in the facade with completely plastered cover panels and guide profiles
• No need for additional cover panel fixation
• Thermal bridges are prevented
• Drop profile retracts completely into the cover panel
• High wind stability up to a maximum wind speed of 93mph
• No incidence of light between guide rail and sun shading product
• The electronic special drive reacts sensitively to obstructions and wind, guaranteeing maximum fabric protection

Features

• Max. width:* 13.12 ft
• Max. height:* 14.76 ft
• Guidance: Directly integrated in the guide rail with ZIP (zipper), (also available with rail guidance, cable guidance, drop arm or as markisolette)
• Installation: Directly on the window frame
• Drive: Motor, optional: radio motor
• Fields of application: New buildings, renovations
• Fabric: Screen, Soltis 92, Standard/Lumera acrylic, All Weather acrylic, Perfora acrylic, Twilight Pearl/Metal, WAREMA SecuTex fabric A2

*depending on type and equipment

Brilliant extras

• Integrated fall protection VisioNeo
